Cisco (EHWIC-4G-LTE-AU=) 4G LTE Wireless WAN Enhanced High-speed WAN Interface Card

Cisco Systems, Inc

EHWIC-4G-LTE-AU=

http://www.cisco.com/c/en_au

Cisco

4G LTE Wireless WAN Enhanced High-speed WAN Interface Card

The Cisco 4G LTE WWAN EHWICs are tightly integrated with the services provided on the award-winning Cisco ISR G2 devices, which deliver secure data, voice, video, and mobility services. The Cisco 4G LTE WWAN EHWICs are supported on the modular Cisco 1900, 2900, and 3900 Series ISR G2 devices.

Enterprises are looking for ways to reduce deployment time, enable comprehensive media services, increase revenue, and improve business continuity. The Cisco 4G LTE WWAN EHWICs, when coupled with a service provider's wireless data plan, provide a rapidly deployable, high-bandwidth, reliable, and secure solution for branch offices and remote sites. With 4G LTE data rates, the Cisco 4G LTE WWAN EHWICs offer a primary WAN link solution capable of running comprehensive branch-office services, including voice and video services.

Radio Modem

19.1 mm

78.2 mm

124.5 mm

147.4 g

EHWIC-4G-LTE-AU is a dedicated Multimode LTE SKU for wireless networks in Australia and New Zealand. EHWIC-4G-LTE-AU comes with a Sierra Wireless MC7304 modem

For LTE:

• 800 MHz (band 20)
• 900 MHz (band 8)
• 1800 MHz (band 3)
• 2100 MHz (band 1)
• 2600 MHz (band 7)

For UMTS/HSPA+/HSPA:

• 800 MHz (band 6)
• 850 MHz (band 5)
• 900 MHz (band 8)
• 1900 MHz (band 2)
• 2100 MHz (band 1)

For GSM/EDGE/GPRS:

• 850 MHz
• 900 MHz
• 1800 MHz
• 1900 MHz

Safety:

• UL 60950-1,CAN/CSA-C22.2 No. 60950-1
• EN 60950-1
• IEC 60950-1
• AS/NZS 60950.1
• FCC Part 2.1093
• RSS-102
• EN 50385

EMC:

• FCC Part 15
• Industry Canada ICES-003
• EN 301 489-01
• EN 301 489-07
• EN 301 489-24
• EN55022 (CISPR22)
• EN55024 (CISPR24)
• EN300-386
• EN 61000-3-2
• EN 61000-3-3
• AS/NZS CISPR 22
• CNS13438
• VCCI V-3

Radio:

• FCC Part 2
• FCC Part 22
• FCC Part 24
• RSS 129 and RSS 133
• RSS 132 and RSS 133
• EN 301 511 GSM
• EN 301 908-1
• EN 301 908-2

90 Day
